Utility loops are continuously circulating pipelines designed to deliver critical utilities throughout Pharmaceutical facility. While maintaining consistent quality, temp, & flow. Ensuring uninterrupted supply & compliance with stringent pharma Standards.
Utility loops are continuously circulating pipelines designed to deliver critical utilities throughout Pharmaceutical facility. While maintaining consistent quality, temp, & flow. Ensuring uninterrupted supply & compliance with stringent pharma Standards.
Typically used for
- Purified Water (PW)
- Water For Injection (WFI)
- Clean Steam
- Technical Steam
- Compressed Air
- Nitrogen & other clean gases
- Process Chemicals
- CIP & SIP Return line
Key Features
- cGMP & FDA compliant design for pharma & biotech cleanrooms
- High Purity construction using SS316L with electropolished (EP) finish.
- Dead Leg free loop design ensuring zero contamination & smooth flow.
- Low Maintenance & long operational life.
- Flexible multi point distribution with optimized routing.
- Hygienic nozzles & Tri clamp connections for quick service.
- Proper marked identification for traceability & validation.
- Custom made Pendants.
Applications in Pharma & Biotech
- Injectable & sterile formulation plants
- Oral Solid dosage (OSD) facilities.
- Fermentation & biochemical plants.
- API manufacturing units.
- Cleanroom utilities.
- CIP/SIP piping systems.
- R&D and QC Laboratory utility points.
Loop Types
Utility Loops
- PW Loop.
- WFI Loop.
- Clean steam loop.
- Nitrogen/Clean Gas loop.
Pendants
- Single Utility Pendant.
- Multi Utility Pendant.
- Sampling Pendants.
- CIP/SIP Pendants.
- Customized Operator Pendants.
Materials & Standards
- Materials- SS316L, EP finish (Ra<0.4micronm).
- Stds- ASME BPE, ISO, cGMP, FDA, EN Hygienic Norms.
- Welding:- Orbital TIG Welding with 100% documentation.
- Testing:- Hydrotest, Boroscope, surface Roughness Test.
