Sugar Syrup Tank

We manufacture Sugar Syrup Storage & Mixing Tanks designed for Pharmaceutical, Food & Beverage, Confectionery and Industrial Applications. Our tanks ensure hygienic storage, uniform mixing, controlled heating and contamination-free handling of sugar syrup.
Manufactured using SS 304 / SS 316L with sanitary design, smooth internal finish and cGMP compliant fabrication suitable for sterile and clean processing environments.

Parameter Details
Capacity 100 L to 10,000 L (Customized)
Material of Construction SS 304 / SS 316L
Internal Finish Mirror / Electro Polish (0.4 – 0.8 Ra)
External Finish Matt / Mirror
Tank Type Jacketed / Non-Jacketed
Insulation Rockwool / Polyurethane Optional
Agitator Top Mounted / Bottom Mounted
Mixing Type Anchor / Turbine / Propeller
Heating System Steam / Electrical / Hot Water
Design Pressure Atmospheric / Pressurized
Design Temperature Ambient to 120°C
Manhole Provided
Inlet / Outlet Hygienic Ferrule / Tri-Clamp Connections
Level Indicator Sight Glass / Level Sensor
CIP / SIP Available (For Pharma)
Mounting Skid Mounted / Leg Mounted

Design Features

  • cGMP & Hygienic Design
  • Smooth Internal Surface to Avoid Bacterial Growth
  • Orbital Welding
  • Leak-proof Construction
  • Sanitary Gaskets & Fittings
  • Drain Point with Slope Bottom
  • Optional Load Cell Integration, Temperature & Level Control Provision

Compliance & Standards

  • cGMP
  • WHO Guidelines
  • FDA / Food Grade Compliance
  • ASME / IS Standard Design
  • Suitable for Pharma & Food Industry Use

Applications

1. Pharmaceutical Industry

Oral Liquid Preparation
Oral Liquid Preparation
Syrup Manufacturing
Syrup Manufacturing
API
API

2. Food & Beverage

Soft Drink Plants
Soft Drink Plants
Dairy & Beverages
Dairy & Beverages
Confectionary
Confectionary
Ice Cream Productions
Ice Cream Productions

Advantages

  • Hygienic & Contamination-Free Storage
  • Uniform Heating & Mixing
  • Easily Cleaning & Maintenance
  • Robust Construction
  • Ready for Automation Integration

Loop Types

Utility Loops

  • PW Loop.
  • WFI Loop.
  • Clean steam loop.
  • Nitrogen/Clean Gas loop.

Pendants

  • Single Utility Pendant.
  • Multi Utility Pendant.
  • Sampling Pendants.
  • CIP/SIP Pendants.
  • Customized Operator Pendants.

Materials & Standards

  • Materials- SS316L, EP finish (Ra<0.4micronm).
  • Stds- ASME BPE, ISO, cGMP, FDA, EN Hygienic Norms.
  • Welding:- Orbital TIG Welding with 100% documentation.
  • Testing:- Hydrotest, Boroscope, surface Roughness Test.
